19-0215
19-0215 - Transmission Sprocket 23 Tooth

York

19-0215 - Transmission Sprocket 23 Tooth

$63.00 Sale • Save

SKU19-0215

Item is in stock Only 10 left in stock Item is out of stock Item is unavailable

23 Tooth transmission sprocket with 2 holes and an .810 offset. For 5 speed models.
Allows the installation of a 180 tire without transmission offset. .900 offset is the maximum offset without any modification to the stock inner primary.

UOM: EA
Country Of Origin: TAIWAN

Accessory Items:
20-0308 - Front Belt Drive Lock Plate and Nut Kit
12-0530 - Transmission Drive Sprocket Nut
12-0566 - Transmission Sprocket Nut
17-1160 - Oil Seal Retainer Kit

Tech Notes: .810inch offset is measured from the back side of the teeth to the back side of the sprocket excluding the flange. 1.236inch offset is measured from the center line of the teeth to the top of the flange on the back side of the sprocket. Suggested to use with #20-0217 Pulley Indexing Flange Nut.
