45-0378 - 16 Wire Wheel Cover Set Chrome by V-Twin

V-Twin

45-0378 - 16 Wire Wheel Cover Set Chrome

$169.00 Sale • Save

SKU 45-0378

Item is in stock Only 10 left in stock Item is out of stock Item is unavailable

16 inch chrome front wire wheel cover set includes 1 cover with a hex hole and the other chrome cover with a 4.1 inch round hole. Set is for pentagon shaped hub flange wheels. For single disc brake wire spoke wheel. Wheel cover will fit rims/wheels with side valves. *NOTE: When filling center valve tube applications cover must be removed. *NOTE: The customer must drill a 5/16 inch hole for the valve stem. Use 1/8 inch drill for pilot hole after locating the inch5 inch mounting holes. Hex hole side has 4 mounting holes used as a template to drill the other cover with the 4/1 inch round hole. *NOTE: The side with the lug bolt holes install first the side with the pentagon hole align with valve stem and install. The last step is to install (4) screws to hold both covers together in place. *NOTE: Side Valve stem hole is 18.5mm for metal stem tubes with nut.

FITS
  • 1973-1984 FL - front
  • 1973-1984 FX - rear
  • 1986-1999 FX - rear
  • 1986-1999 XL - rear

ACCESSORIES
  • 73-0078 - Fillister Head Screw 8-32 N.C. X 3/8 inch Zinc
  • 37-0931 - Wheel Cover Stainless Steel 6-32 Bolt and Nut Kit
TECHNICAL SPECIFICATIONS
  • Suggested to use with #45-0365 16inch Front Wheel Cover Set Chrome.
  • Suggested to use with #46-0115 5.10 x 16inch Tube Side Valve Metal Stem.
  • Suggested to use with #37-0931 Wheel Cover Stainless Steel 6-32 Bolt and Nut Kit.
