50-0922 - Bobbed Fender Mount Brace Chrome

Rigid bobbed fender mount brace is chrome with preformed bends of heavy 1/4 inch steel. For use with a 5 inch or 6 inch fender. The inside of the top mount to the center of the bottom measures 13-1/8 inch. The top of the top mount to the center bottom mount measures 14 inch. The bottom bolt holes to the top of the brace measures 13 inch. The bottom mount to the top mount features a 13 inch outer diameter and a 12-7/8 inch inner diameter.

MEASUREMENTS

• Top Width: 5-7/16
• Width: 9-1/4 inches
• Bottom Width: 9-1/4 inches
• Bottom Mounts O.D.: 10-5/8 inches
• Bottom Mounts I.D.: 10-1/8 inches
• Bar: 1 inches
• Top of Bar O.D.: 6 inches
• Top of Bar I.D.: 5-9/16 inches
